Specifications - Kramatorsk NKMZ 4000 (ID:76209)
| Type | Hot forging press |
| Manufacturer | Kramatorsk NKMZ |
| Model | 4000 |
| Nominal force | 4000 ton |
| Slide stroke | 400 mm |
| Number of slide continuous strokes per minute |
50 |
| Shut height (distance between bed in top position and slide bolster plate, stroke down) |
1000 mm |
| Bed adjustment | 15 mm |
| Distance between uprights clear | 1660 |
| Slide dimensions | |
| left-to-right | 1420 mm |
| front-to-back | 1420 mm |
| Bed dimensions | |
| left-to-right | 1570 mm |
| front-to-back | 1620 mm |
| Upper knockout stroke | 60 mm |
| Down knockout stroke | 125 mm |
| Uprights openings dimensions | |
| width | 770 mm |
| height | 995 mm |
| Main motor power | 185 kW |
| Overall dimensions | |
| left-to-right | 6100 mm |
| front-to-back | 4710 mm |
| height | 8680 mm |
| Height above floor level | 6820 |
| Mass | 400 ton |
Hot forging press for sale: Hot forging press Kramatorsk NKMZ 4000 - 4000 ton (ID:76209). All details of this offer (availability, condition, price, delivery terms) will be sent to you by our manager, please click "Send inquiry". We can also help with finding other equipment for your needs.
