Barnaul KB8340 knuckle joint press - description

Knuckle joint press Barnaul KB8340 — 1000 ton (ID:76273) is an industrial press with a knuckle-joint mechanism that delivers high force with a short ram stroke. The machine achieves significant pressure at the final stage of the working cycle while maintaining relatively compact dimensions. Used for coining, calibration, and cold stamping operations where a short but powerful force application is required.

Technical specifications Barnaul KB8340 (ID:76273)

TypeKnuckle joint press
ManufacturerBarnaul
ModelKB8340
Year of manufacture1984
Force1000 ton
Stroke170 mm
Number of strokes per minute32
Shut height470 mm
Adjustment16 mm
Table size800 x 800 mm
Bolster plate thickness140 mm
Bottom ejector
Stroke110 mm
Force320 kN
Top ejector
Stroke10 mm
Force100 kN
Overall dimensions2950 x 1950 x 4090 mm
Weight27500 kg
