Hydraulic forging hammer Lasco KH 200 — 20 kJ
Lasco KH 200 hydraulic forging hammer - description
Technical specifications Lasco KH 200 (ID:76299)
| Type | Hydraulic forging hammer |
| Manufacturer | Lasco |
| Model | KH 200 |
| Blow energy | 2000 kgm |
| Maxi falling height with standard tool | 1100 mm |
| Weight for falling tup | 1800 kg |
| Height of die | 180 mm |
| Max. weight for die | 340 Kg |
| Way between guides | 625 mm |
| Lenght of ram | 560 mm |
| Motor | 27 kW |
| Total height of hammer | 6150 mm |
| Total height over the floor | 5300 mm |
| Weight of the anvil block | 21 ton |
| Total weight of hammer | 43 ton |
Hydraulic forging hammer Lasco KH 200 - technological processes and operations
| Forging | The process of plastic deformation of metal, in which the workpiece changes shape under the impact of blows or static pressure. During forging, the metal structure is densified, internal inhomogeneities are eliminated, and the mechanical properties of the material are improved. As a result, forged products are distinguished by high strength and reliability when operating under significant loads. Forging is used both for producing finished parts and for preparing workpieces for subsequent stamping. |
| Closed-die forging | The workpiece is deformed inside a die cavity that restricts metal flow, forcing it to fill the exact shape of the tool. Under high pressure, the material spreads into every recess and detail of the die, producing a part with precise geometry. This method provides high accuracy and repeatability, making it the standard for series and mass production of complex forgings. |
| Drop forging | A method of hot closed-die forging in which the workpiece is deformed by the energy of a falling ram. Under the impact, the metal fills the die cavity, reproducing its geometry and taking the shape of the finished part. The process is characterized by high productivity and repeatability, making it in demand in series and mass production. |
